Description
Norsat’s band pass filters reject terrestrial interference in C-Band (including 5G) and can be easily installed between the feed and an LNB. It is suitable for use with Norsat’s existing C-Band LNBs and is environmentally sealed and moisture resistant (IP66). BPF / BPF-C Series.
| KEY SPECIFICATIONS | |
| Product Family | Standard C-Band BPF |
| Band | C-Band |
| Input Frequency – Band * | C-Band: * |
| RF SPECIFICATIONS | |
| Output VSWR | 1.4 : 1 |
| INTERFACE SPECIFICATIONS | |
| RF Input Connector | CPR 229G waveguide grooved |
| RF Output Connector | CPR-229F |
| PHYSICAL SPECIFICATIONS | |
| Dimensions (L x W x H) | 120 x 100 x 70 mm |
| Weight | 0.65 kg |
* Bandpass Frequency’s
1: BPF-C-1: 3.70 to 4.20 GHz
2: BPF-C-2: 3.625 to 4.20 GHz
3: BPF-C-3: 3.754 to 4.20 GHz
4: BPF-C-4: 3.80 to 4.20 GHz
5: BPF-C-5: 3.90 to 4.20 GHz
6: BPF-C-6: 4.00 to 4.20 GHz
